A large-scale fNIRS sensorimotor benchmark

Functional near-infrared spectroscopy from 109 participants performing right-hand hand clenching and finger tapping. Twenty trials, thirteen channels, three hundred and six samples — preview the preprocessed data in your browser before downloading the raw release.

Simona Klinkhammer^a*, Tim Näher^b,c, Sophie Raible^a, Michael Lührs^a,d, Franziska Klein^e,f, Bettina Sorger^a * s.klinkhammer@maastrichtuniversity.nl

Show affiliations

^aDepartment of Cognitive Neuroscience, Maastricht University, Maastricht, The Netherlands
^bMax Planck Institute for Biological Cybernetics, Tübingen, Germany
^cMeta Reality Labs, Seattle, Washington, United States
^dBrain Innovation B.V., Maastricht, The Netherlands
^eAssistance Systems and Medical Device Technology, Department of Health Services Research, University of Oldenburg, Oldenburg, Germany
^fBiomedical Devices and Systems Group, R&D Division Health, OFFIS — Institute of Information Technology, Oldenburg, Germany

Download data Paper Repository with example code

109

Participants

2 × 10

Trials / subject

Channels

10.17 Hz

Sampling

30 s

Epoch

Grand average · Channel 04 · n = 109 Δ HbO / HbR (z)

Paradigm

Block design. Visually cued right-hand clenching (cond 1) and finger tapping (cond 2). 10 s task / ~20 s rest, ten trials per condition, 30-second epoch from −5 → +25 s around stim onset.

Signal

HbO / HbR concentrations across 13 channels over the left-hemispheric motor cortex, sampled at 10.173 Hz. Motion-corrected, band-pass filtered, and z-scored per channel; displayed with pre-stim baseline correction.

Format

Public release: raw BIDS / SNIRF, one folder per participant, with _events.tsv, _optodes.tsv, and BIDS sidecars. This dashboard shows preprocessed example tensors derived via the published pipeline.

What to look for

A canonical hemodynamic response: HbO rises, HbR falls. Effect is strongest on motor-cortex channels 02, 04, 08, 09, weaker elsewhere.

A large-scale fNIRS sensorimotor benchmark

Paradigm

Signal

Format

What to look for

Grand average · Channel 04

All 13 channels · grand average

All channels · grand average · Hand Clenching
